Welcome to the new FURUNO FCV 588 The ultimate Fishfinder
Posted by Shotgun Shelly on 2nd Nov 2015
Furuno have just launched the new Furuno Fishfinder FCV 588
Check it out now Available today
SPECIFICATIONs Quick overview Furuno FCV 588
DISPLAY
* Display unit: 8.4" TFT colour LCD
* Pixel number: 480 x 640
FISH FINDER
* Frequency: 50 and 200 kHz
* Transducer: 600 W/1 kW* (The FCV-588 can be connected with the transducers of 1 kw output power, when interfaced with the Matching Box MB-1100).
* Range Scale: 2-1200 m
* Pulse length & PRR: 0.1-3 ms, Max 3,000 pulse/min
* Display Mode: Single frequency (50 or 200 kHz), Dual-frequency, Zoom, Navigation info, A-scope, Marker zoom, Bottom zoom, Bottom-lock, Bottom Discrimination, ACCU-FISH™
* Waterproofing: IP56
* Power Supply: 12-24 VDC : 1.2 - 0.6 A
* Size (mm): 270 (H) x 233 (W) x 158 (D)
* Weight Bracket Mount: 2.3 kg
* Flush Mount: 1.6 kg Specifications
Sunlight Viewable, Polarised Friendly. 8/16/64 Color Echo Presentations 8.4" Super Bright Colour LCD display - 640 x 480VGA
White Line feature helps discriminate fish lying near the bottom
Frequency: 50/200khz
Output Power: 600W/1kW rms
Hands free corrections of gain, STC & output power through digital filtering
Visual and sound alarms for water depth, fish echoes and water temperature
Alarms: Bottom, Fish (bottom lock and normal), Speed, Water Temperature and Arrival Speed, require appropriate sensor)
Wide variety of T/H, T/M Biducer and Triducer Transducer options
